Easy installation industrial integrated all in one air cooled screw chiller
An industrial process chiller with integrated pump and external water tanks is a customized chiller package designed for specific process cooling applications. It is equipped with a built-in pump and external water tanks to ensure efficient and consistent cooling for industrial processes.
Fully Packaged chiller with Integrated Pump and Tank , designed for engineers at site with simple installation and time-saving. The chiller is assembled with built-in pump and tank ,as well as filled with refrigerant and lubricating oil during production, the customer only needs to connect the inlet & outlet pipes and the power supply to operate the unit. The control interface directly show the fault content, convenient to identify the fault and fix timely.
The main features of such a chiller package include:
Integrated Pump: The chiller comes with a pump that circulates the chilled water through the process equipment. The built-in pump ensures proper flow and pressure for efficient cooling.
External Water Tanks: The external water tanks provide a large capacity for storing chilled water, ensuring a stable supply to the process equipment. The tanks can be customized in size to meet the specific cooling requirements of the application.
Customization: The chiller package is tailored to the specific needs of the customer. It can be designed with the desired cooling capacity, temperature range, and control options to suit the industrial process.
Energy Efficiency: The chiller package is designed to be energy-efficient, incorporating features such as variable speed drives and intelligent control systems to optimize performance and reduce energy consumption.
Compact Design: The chiller package is designed to be compact, occupying minimal floor space in the industrial facility. It can be installed indoors or outdoors, depending on the requirements and available space.
Easy Installation and Maintenance: The chiller package is designed for ease of installation and maintenance. It is equipped with accessible components and user-friendly controls, making it convenient for routine maintenance tasks.
Overall, an industrial process chiller with integrated pump and external water tanks provides a comprehensive and customized solution for efficient and reliable process cooling in various industrial applications.
Compressor features:
•New screw type compressor with 20%-30% higher in efficiency.
•Cooling capacity control available at four steps (100%-75%-50%-25%), three steps (100%-66%-33%) or no steps control system.
•High efficiency, low noise and vibration, easy to install.
•Environmental protection refrigerant R134a, R407c available.
Control operation system:
•SIEMENS PLC program control system, human-computer interface with big LED touch panel, running state displaying in multi-language, and self-diagnosis for easy operation and supervision.
•Extended industrial interface, convenient for being computer monitor via network.
Completely safety protection function:
•Multisafety protection by high and low pressure, compressor overheating, overloading, over temperature, flow switch, phase sequence, phase-missing, exhaust overheating and anti-freezing.
Air-Cooled Screw Chiller Products Information
Features:
1. The compressor adopts the international brand. The original imported international brand BITZER Germany (Bitzer) HANBELL China Taiwan (Hanbell), a new type of high-efficiency screw rotor compressor, the efficiency is 20%-30% higher than the general compressor.
2. High efficiency 5:6 patented asymmetric rotor tooth profile.
3. Capacity control can adopt four-stage (100%-75%-50%-25%) or three-stage (100%-66%-33%) and stepless control system.
4. The combined design of 11 bearings and a-type axial thrust balance drum greatly increases the bearing life by 2.5-3.5 times.
5. The use of high-efficiency silicon steel sheet special groove design, and equipped with internal and external omnidirectional design cooling channel, so that the compressor motor can play the highest efficiency under any load.
6. The unique built-in oil pressure system does not need an oil pump to ensure that the compressor maintains the best lubrication effect. The oil separator adopts a double-layer filter method, which has a good oil filtering effect and the heat exchanger can exert its maximum capacity.
7. High efficiency, low noise and low vibration.
8. A variety of refrigerants are available. In addition to R22 refrigerant, environmentally friendly refrigerants such as R134a and R407c can also be used.
Application range of air-cooled screw
chiller:
Product Application of air cooled water chillers are used for controlled cooling temperature of products, mechanisms and factory machinery in a wide range . Plastics – injection moulding, PET, blow moulding, woven sack extrusion, sheet and profile...
Product Specification
Specification Based on 1 C Outlet tempertaure
| Item Model | OMC-100ASH | ||
| Cooling Capacity | kcal/h | 222740 | |
| KW | 259 | ||
| Ton | 73.6 | ||
| Input Power | KW | 57.4 | |
| Max. running current | A | 160.6 | |
| Power | 3ph-380V-50Hz | ||
| Refrigerant | Type | R407C | |
| Charge quantity | kg | 70 | |
| Control Mode | Expansion Valve | ||
| Compressor | Type | Semi-Hermetic Screw | |
| Power | KW | 92.9 | |
| Start-up Mode | Y-△ | ||
| Capacity control | ％ | 0-25-50-75-100 (0-33-66-100) | |
| Evaporator | Type | Shell and Tube | |
| Chilled water flow | m3/h | 44.5 | |
| Pipe Diameter | lnch | 4＂ | |
| Condenser | Type | Air cooled high-efficient inner threaded copper-tubing aluminum fin type | |
| Fan | Type | Low noise outer rotor | |
| Power | KW | 7.2 | |
| cooling air flow | m3/h | 100000 | |
| safety protection |
compressor over heat protection, over load protection, high and low pressure protection, reversed and lacking phase protection, anti-freezing protection, flow switch |
||
| Dimension | Length | mm | 4000 |
| Width | mm | 2250 | |
| Height | mm | 2300 | |
| Net Weight | kg | 2860 | |
| Running Weight | kg | 3020 | |
Packing & Shipping
FAQ
Q1: Could you help us to recommend the model for our project?
A1: Yes, we have engineer to check the details and make the scheme for you. Based on the following:
1)Cooling capacity;
2)chilled water inlet and outlet temperature
3)chilled water flow
4) Refrigerant;
5) Ambient temperature;
6)Voltage;
7) Be used for what industry?
8)Any other special requirements?
Q2: How to ensure your product with good quality?
A2: All our products with CE certificate. And use the well-know brand accessories, such as copeland, danfoss,Hanbell, Bitzer compressor Emerson expansion Valve, Siemens controller.
also can be customized. All OUMAL Chillers are factory tested under load conditions to ensure good quality and easy installation for users
Q3: What's the warranty?
A3: 15 months warranty for free if confirmed by both side damage in the quality reason.
Q4: Whats your payment term?
A4: We accept T/T, LC, Western Union, etc. Normally, 30% deposit for production, 70% balance before shipment.
Q5: Are you a manufacturer?
A5: Yes, we have more than 15 years in water chiller business. Also have patent on the water chiller appearance.
The control box design make the unit safety and stably.
Q6: How can i Place an order ?
A6: Click Below to fill the table or Call 0086 15112554736, [email protected]
